Karakteristikler
| LOA - 19.92m (65'4") | LOD - 15.92m (52'3") | LWL 13.20m (43'4") | Beam 4.80m (15'9") |
| Draft 2.10m (6'11") | Displacement (1/2 load) 29500kg (65018lb) | Lead ballast 5000kg (11020lb) | Water ballast 5600kg (12342lb) |
| Area Waterplane 37.6sq.m (405sq.ft) | Immersion Rate 385kg/cm (2155lb/inch) | Fineness Coef 0.67 | Block Coef 0.45 |
| Prismatic Coef 0.57 | Displacement/Length 302 | Wetted surface 66.3sq.m (714sq.ft) | Sail Area (Working) 118.1sq.m (1271sq.ft) |
| Sail Area/Wetted Surface 1.8 | Sail Area/Displ 12.5 | Righting Moment @ 30 deg 16377 kgm (118455ft.lb) | Righting Moment @ 60 deg 23586 kgm (170598ft.lb) |
| Righting Moment @ 90 deg 23985 kgm (173484ft.lb) | Cargo capacity 25 tons | Fuel tankage 3000litres (1090 US gals) | Powering 100-150hp inboard diesel |
