Karakteristikler
| LOD 12.00m (39'4") | LWL 10.30m (33'9") | Beam 3.90m (12'10") | Draft 1.80m (5'11") |
| Displacement 9800kg (21600lb) | Ballast 3800kg (8375lb) | Area Waterplane 22.18sq.m (239sq.ft) | Immersion Rate 227kg/cm (1271lb/inch) |
| Wetted Surface 34.57sq.m (372sq.ft) | Fineness Coef 0.62 | Block Coef 0.41 | Prismatic Coef 0.52 |
| Displacement/Length 258 | Sail Area (Main + Fore-triangle) 78.2sq.m (842sq.ft) | Sail Area/Wetted Surface 2.26 | Sail Area/Displ 17.3 |
| Righting Moment @ 30 deg 6464 kgm (46754ft.lb) | Righting Moment @ 60 deg 8683 kgm (62804ft.lb) | Righting Moment @ 90 deg 6800 kgm (49184ft.lb) | Powering35-50hp inboard diesel |
